Mechanical Type 3 Rollers Rolling and Bending Machine/ Pipe Forming Machine/Sheet Metal

Introducing the W11-252500mm Series Mechanical Type 3 Rollers Rolling and Bending Machine - the perfect solution for all your metalworking needs! This powerful and versatile machine is designed to handle a wide range of materials, from pipes to sheets, and can bend them with ease. With its mechanical 3-roller design, this machine can achieve precision bends and curves, making it perfect for use in metal fabrication, construction, and other industries. The robust construction of this machine ensures that it can withstand the rigours of heavy-duty use, while its compact size makes it easy to manoeuvre. Don't settle for anything less than the best - choose the W11-252500mm Series Mechanical Type 3 Rollers Rolling and Bending Machine for all your metalworking needs.

Disclaimer:

Please note that the W11-25*2500mm Series Mechanical Type 3 Rollers Rolling and Bending Machine is a heavy-duty machine designed for use in metal fabrication, construction, and other industrial applications. As such, it should only be operated by trained and experienced professionals who understand the proper safety protocols and guidelines for working with heavy machinery. We strongly advise that you carefully read and follow all instructions and warnings provided by the manufacturer before operating this machine. Additionally, please be aware that the use of this machine may be subject to certain regulations and restrictions in your area, and it is your responsibility to ensure compliance with all relevant laws and regulations. Finally, please note that while we are confident in the quality and performance of our product, we cannot be held liable for any damages or injuries that may result from the use of this machine.

W11-25*2500mm Series Mechanical Type 3 Rollers Rolling and Bending Machine/ Pipe Forming Machine/Sheet Metal Bending Machine

This belongs to three roller plate rolling machine,up roller is fixed and it is the main drive,hydraulic motor driven by variable speed drive gear up and down roller belt drive, to provide torque for the roll sheet; under the roller moves vertically through the hydraulic pressure acting on the piston of hydraulic cylinder obtained in order to clamp plate for hydraulic transmission; the down roll of the sides with side roller and cylinder driven by oil.The machine advantage of end plate bending(pre-bending) and rolling can be conducted on the same machine

Structure and main parts:

This equipment composed of work frame , upper roll device , main drive device, down roll device, side roll device, overturn device ,hydraulic system(parts) , electricity system(parts), and  lubricate device .

Work frame:

Body from the base, a fixed side frame and the tip side of the rack, and each part is steel welded structure. Were fixed with bolts on both sides of the rack in the base and sides of the rack will be used to connect beams connected to rigidity good. Both sides of the rack up roller and side rollers with movement of rail, fixed on the side of the rack with roller bearing for half of the closed frame structure, has overturned side rack shelf support devices. Coil force in the process of both sides of the rack by the bear from the base not only supports the weight of the machine to ensure the accuracy of the role of equipment, but also enables a torque between the drive and chassis balance, and will join into one machine. In the now traditional large-scale four-roller bending machine body and the main gear is separate from the base installation.

Details:

1. Main power:Siemens Electrical made in Germany
2. Main electronic elements: Schneider made in France;
3. Axletree:Double-row self-aligning bearingfrom Germany
4. Main motor: Siemens Electrical made in Germany
5. Programmable logic controller PLC:OMRON products from Japan
6. Hydraulic system: Bosch - Rexroth made inGermany
7. Gear pump: made in China TaiWan ;
8. Work Roller:Material of work roller with 42CrMo Alloy steel.
9. Digital display system:Touch Screen for Delta
10 Transducer:OMRON,Made in Japan
11. Automatic lubrication system:Sino-Japanese joint,which has block alarm
W12 Four-roller Rolling machine, plate rolling machine, hydraulic bending machine, 4-roller rolling machine,
W11 Three-roller rolling machine,plate,rolling machine

Technical Parameters

Shipping & Packing

Each Mechanical Rolling Bending Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers
and ship them abroad.
